Performance
- Gear ratio 5,3:1
- Pulling capacity 1st layer 4500 kg. [10000 lbs.]
- Speed line (based on 60 lt/min. [16 gpm] oil supply):
1st layer 13,3 mt./min. [43,6 ft./min.]
4th layer 21,6 mt./min. [70,9 ft./min.]
Features
- Single stage hardened steel planetary gears in oil bath
- Hydraulic multi disc negative brake system
- Over-centre valve
- Manual Clutch for drum Freespooling
- Hydraulic orbital motor
- Drum length (distance between drum flanges): EPH 4500 FN standard drum 252 mm [9,9 in]
- Drum barrel dia.102 mm [4,0 in]
- Wire rope recommended dia.12 mm
Compliance
CE Machinery Directive 98/37/EEC
Accessories
- Galvanized Heavy-duty roller fairlead (rollers in steel)
- Galvanized level winder
- Air clutch for drum Frees-pooling
