Port sizes: 1/2” ÷ 3”
Flow rates: 3 ÷ 1.200 l/min
Technical Data
Max. working pressure: 2 MPa (20 bar)
Max. test pressure: 3 MPa (30 bar)
Bursting pressure: 6 MPa (60 bar)
Fatigue test: 0 ÷ 1,5 MPa (15 bar) / 1.000.000 cycles Bypass valve: return ∆p 300 kPa (3 bar) ±10%
suction ∆p 30 kPa (0,3 bar) ±10%
Filter element collapse pressure:
standard: ∆p 1 MPa (10 bar)
Working temperature: -25 ÷ +110°C
Materials
Head and bowl: anodized aluminium steel for MSE250
Bowl type 250: anodized steel
Seals: standard NBR on request FKM
Compatibility (ISO 2943)
Full with fluids: HH-HL-HM-HV-HTG
(according to ISO 6743/4).
For fluids different than the above mentioned, please contact our Sales Department.
