HP
Technical features
- Maximum working pressure (PS): 250 bar
- Test pressure (PT): PS x 1,43 / 1,3 / 1,5
- Construction method : carbon steel body with piston made in aluminium
- Standard nitrogen valve : ⅝” UNF
- Working temperature (TS): -20°C ÷ +80°C
- Seals: standard execution in NBR
- Installation: in every position
- Compression Ratio: It does not require compliance with defined parameters
Available:
- Outside epoxy painted as per standard FOX procedure or as project specification
- Seal in Polyurethane, FPM, PTFE
- Connection with flange SAE 3000 – SAE 6000, ANSI B16.5 or UNI/DIN
- Special connection on request
- High pressure version
- Special volume on request
- X series in SS316L or exotic materia
Model
HP60-0,3 - HP60-0,5 - HP80-0,5 - HP80-0,7 - HP80-1 - HP80-1,5 - HP100-1 - HP100-2 - HP100-3 - HP100-4 - HP100-5 - HP100-6
